1812 Plus

Updated version of the Classic with an upgraded processor, a new high fidelity digital voice circuit, better volume control, a lighted push-button, and additional call out to up to 27 telephone numbers.

Overview

Features

Tech Specs

Resources

Accessories

1812 Plus

Ideal for Single Family with Multiple Users

The 1812 Plus is an updated version of the 1812 Classic and features an upgraded processor, a new high fidelity digital voice circuit, better volume control, a lighted push-button and additional call out telephone numbers (up to 27). This unique communication and access control system allows homeowners to use their existing telephone as an intercom to speak with a guest at a door or gate and is ideal for those applications requiring a basic, single door or gate, access control solution.

Communicate with Guests via Phone

Entry System Programming via System or Telephone Keypad

Uses Existing Phone Line as High Fidelity Intercom

Applications

Small Multi-Family Residential

Mixed Use Buildings

Commercial & Industrial

Product Features

Voice Communication

Unique communication and access control system allows homeowners to use their telephone as an intercom to speak to a guest at a front door or gate. The system provides added security and privacy by allowing homeowners to screen visitors before granting access to the property.

Ideal for Single Family with Multiple Users

The 1812 Plus Telephone Entry System is well-suited for single-family residences with multiple users. This entry system is capable of standard door and gate access.

Additional Access Point Control

Add Additional Access Point Control with keypads, card readers or RF receiver

Features

Built-in time clock / calendar • Entry code time zones • Call forwarding time zone • 4 hold open time zones • Do not disturb time zone • Flash entry codes

Grant Guest Access

Easily grant guest access by pressing “9” on the telephone.

Modular Design

Created to make installation and service easy.

Technical Specifications

Specifications

Hands free, full duplex digital audio circuit.
1812 Plus Capacity:
Interfaces with a single phone line
27 dial-out phone numbers
Two relays for door or gate control.
1812 Plus Programming Method: System keypad or touch-tone telephone.
16 VAC, 20 VA (250 ma) power transformer provided.
FCC (US): DUF6VT-12874-OT-0
DOC (CAN): 1736 4507 A
Complies with UL 294; ETL Listed.

Miscellaneous

Environmental: 10°F to 145°F (-12°C to 62°C)
Camera ready: Optional CCTV Camera* *may require additional CCTV equipment
Surface, curved surface or flush mount – specify which.
Stainless steel housing (surface mount only).

Options

Call waiting.
Call forwarding with time zone restrictions.
Unique double ring.
Built-in clock / calendar.
Do-not-disturb feature.
Four “hold open” time zones.
Answer machine bypass feature.
50 5-digit entry codes with time zone restrictions on some codes.
10 Temporary entry codes with start and end dates.
Intercom mode for use with PBX and KSU phone systems.
Camera ready.
Connects directly to your existing C.O. (Central Office) phone line. No additional monthly expense for a separate telephone line to the entry system.
Digital voice circuit for crystal clear communication.
Unique double ring identifies calls from the 1812.
Two relays allow control of two doors or gates.
Answer machine bypass feature allows the homeowner to call the 1812 from an off-site location and “by-pass” a home answering machine to perform programming operations.
Built-in call waiting so calls from the access system are never missed – even if you’re on the phone.
Call forwarding – never miss an access system call, even if you’re away from your home. And you can even create a time zone for when you want your calls to be forwarded.
Dial-out function provides up to 27 alternate phone numbers for the system to call.

Dimensions and Weight – Surface

Shipping weight approximately 15 lb (7 kg)
Surface mount dimensions: 6.13″H x 10″W x 5.25″D.

Mechanical

Call waiting.
Call forwarding with time zone restrictions.
Unique double ring.
Built-in clock / calendar.
Do-not-disturb feature.
Four “hold open” time zones.
Answer machine bypass feature.
50 5-digit entry codes with time zone restrictions on some codes.
10 Temporary entry codes with start and end dates.
Intercom mode for use with PBX and KSU phone systems.
Camera ready.
Connects directly to your existing C.O. (Central Office) phone line. No additional monthly expense for a separate telephone line to the entry system.
Digital voice circuit for crystal clear communication.
Unique double ring identifies calls from the 1812.
Two relays allow control of two doors or gates.
Answer machine bypass feature allows the homeowner to call the 1812 from an off-site location and “by-pass” a home answering machine to perform programming operations.
Built-in call waiting so calls from the access system are never missed – even if you’re on the phone.
Call forwarding – never miss an access system call, even if you’re away from your home. And you can even create a time zone for when you want your calls to be forwarded.
Dial-out function provides up to 27 alternate phone numbers for the system to call.
